Single-Stage Variable-Speed Gas Furnace
AMVS80-U
Traditional Heating & Cooling
- 80% AFUE
- Ultra Low NOx
- Variable-Speed ECM Blower Motor
- Integrated communicating ComfortBridge™ Technology
- Commissioning and diagnostics via indoor board Bluetooth with the CoolCloud™ phone and tablet application
- Heavy-duty stainless-steel dual-diameter tubular heat exchanger
- Single-stage gas valve
- Durable hot-surface igniter
- Quiet modulating induced draft inducer
- Self-diagnostic control board
- Variable-speed ECM blower motor
Features
Quiet Performance
Engineered Longevity
Energy Efficiency
Copeland® CoreSense Diagnostics
Also Includes:
1 in. Filter
AM11 CleanFit
Nest (3rd Gen) Thermostat
Honeywell Pro 9000
Evaporator Coil
You will receive 1 filter and 1 thermostat.
Product Summary
The Traditional AMVS80-U Gas Furnace is a highly efficient, HERS-tested appliance engineered for energy efficiency, quiet operation, and longevity. It is designed to meet California emissions regulatory compliance standards thanks to a clean combustion premix burner that provides the optimal mix of fuel and oxygen. In addition, a multi-speed motor automatically adjusts airflow to not only reduce energy usage but also improve comfort and enable quiet operation (compared to single-stage motors).
A silicon nitride ignitor also conserves energy, as it replaces a pilot light. The sealed combustion design further improves efficiency because it adds heat directly to indoor air rather than exchanging it with outside air. Meanwhile, an insulated cabinet permits air leakage of no more than 2%, which not only reduces blower noise but also improves heat transfer efficiency. The heat exchanger itself is made of 439 stainless steel, formed using wrinkle-bend technology, which improves efficiency and reliability.
The AMVS80-U also integrates smart diagnostics via a pre-programmed control board that provides continuous monitoring. Diagnostic codes are stored in the board’s memory, with LED indication of operating conditions so performance issues can be quickly troubleshooted. When minor issues or detected, cost-saving measures can be taken to restore comfort and avoid costlier repairs.
Other Resources
Specifications
- All jobs are 100% permitted and HERS tested.
- All-Aluminum Coil
- SmartFrame Sub-Structure
- 21" depth for easier attic access
- Check flowrator for cooling and heat pump applications
- Direct drive, multi-speed PSC blower motor
- Cabinet air leakage less than 2.0% at 1.0 inch H₂O when tested in accordance with ASHRAE standard 193
