Electric Heating & Cooling

The Lennox® Mini-VRF heat pump, available in 3- to 5-ton configurations, can control up to 9 zones in residential and light commercial applications. Its inverter-driven compressor adjusts speed based on demand at each indoor unit. Up to 492 feet of refrigerant piping can be installed. The outdoor unit is a compact 52¼” high and 35⅜” wide, suiting a wide range of architectural design requirements.

The Mini-VRF is as quiet as it is energy efficient. It operates at up to 19.2 SEER and 11.4 HSPF. Thanks to an innovative fan blade design, indoor units can operate at as low as 23 dBA. Sound levels at the outdoor unit can go as low as 41 dBA. That’s in addition to a vast array of features that include auto restart after a power failure, automatic assignment of indoor unit addresses, and dry mode for greater humidity control.

A 7” programmable touchscreen controller is built into the Mini-VRF. This full-color display allows you to set temperatures for each zone, create customized heating and cooling schedules, and troubleshoot the system. With the Lennox VRF AHU Control Kit, you can adapt the Mini-VRF to accommodate the maximum amount of piping. It enables two piping connections and simplifies the installation process.

• All jobs are 100% permitted and HERS tested.
• All-Aluminum Coil
• SmartFrame Sub-Structure
• 21" depth for easier attic access
• Check flowrator for cooling and heat pump applications
• Direct drive, multi-speed PSC blower motor
• Cabinet air leakage less than 2.0% at 1.0 inch H₂O when tested in accordance with ASHRAE standard 193
