Traditional Heating & Cooling

Single-Stage Multi-Speed Gas Furnace AM9S80

  • 80% AFUE
  • Heavy-Duty Stainless Steel, Dual-Diameter Tubular Heat Exchanger
  • Multi-Speed ECM Motor
  • Single-stage Gas Valve
  • Durable Hot-surface igniter
  • Quiet, Single-speed Draft Induced
  • Self-diagnostic Control Bboard
  • Color-coded Low-voltage Terminals
  • Heavy-gauge Steel Cabinet with Durable Baked-enamel Finish
  • Foil Faced Insulated Heat Exchanger

Features

Quiet Performance

Engineered Longevity

Energy Efficiency

Copeland® CoreSense Diagnostics

Accessories

1 In. Filter

Honeywell T-6

Evaporator Coil

Product Summary

The Traditional AM9S80 Gas Furnace is a highly efficient, HERS tested appliance engineered for energy efficiency, quiet operation, and longevity. It is designed to meet California emissions regulatory compliance standards thanks to a clean combustion premix burner that provides the optimal mix of fuel and oxygen. In addition, a multi-speed motor automatically adjusts airflow to not only reduce energy usage, but also improve comfort and enable quiet operation (compared to single-stage motors).

A silicon nitride ignitor also conserves energy, as it replaces a pilot light. The sealed combustion design further improves efficiency because it adds heat directly to indoor air rather than exchange it with outside air. Meanwhile, an insulated cabinet permits air leakage of no more than 2%, which not only reduces blower noise but also improves heat transfer efficiency. The heat exchanger itself is made of 439 stainless steel, formed using wrinkle-bend technology, which improves efficiency and reliability.

The AM9S80 also integrates smart diagnostics via a pre-programmed control board that provides continuous monitoring. Diagnostic codes are stored in the board’s memory, with LED indication of operating conditions so performance issues can be quickly troubleshooted. When minor issues or detected, cost-saving measures can be taken to restore comfort and avoid costlier repairs.

Other Resources

NEXGEN Consumer Brochure AM9S80

Download

NEXGEN Technical Specs AM9S80

Download

NEXGEN Lifetime Warranty AM9S80

Download

Specifications

  • All jobs are 100% permitted and HERS tested.
  • All-Aluminum Coil
  • SmartFrame Sub-Structure
  • 21" depth for easier attic access
  • Check flowrator for cooling and heat pump applications
  • Direct drive, multi-speed PSC blower motor
  • Cabinet air leakage less than 2.0% at 1.0 inch H₂O when tested in accordance with ASHRAE standard 193
